Foldable aluminum gantry crane with adjustable height and span
The PRG model Aluminum gantry crane is a height-adjustable, foldable
aluminum gantry crane designed for rapid deployment
and is fully portable. Its load lifting capacity is up to 1000kg.
This mobile gantry crane can be assembled in one minute by one
person without any tools and is the perfect solution for
confined space access scenarios due to its unique features and
ability to lift equipment and personnel.
Product Parameter
| Model | Load
capacity(KG) | Eternalwin Dimension Parameter (mm) | Self weight(KG) |
| A | B | C | D | F | G | H | J | K | L |
| PRGS20 | 500 | 2000 | 2080 | 1100-1500 | 1544-2044 | 1876-2376 | 1158 | 2001-2501 | 2080 | 420 | 440 | 39 |
| PRGS23 | 400 | 2300 | 2380 | 1200-1800 | 2380 | 40 |
| PRGS40 | 250 | 4000 | 4080 | 2700-3500 | 4080 | 46 |
| PRGM20 | 400 | 2000 | 2080 | 1100-1500 | 1548-2148 | 1880-2480 | 1215 | 2005-2605 | 2080 | 40 |
| PRGM23 | 400 | 2300 | 2380 | 1200-1800 | 2380 | 41 |
| PRGM40 | 250 | 4000 | 4080 | 2700-3500 | 4080 | 47 |
| PRGT20 | 250 | 2000 | 2080 | 1100-1500 | 2022-2922 | 2354-3254 | 1586 | 2479-3379 | 2645 | 44 |
| PRGT23 | 250 | 2300 | 2380 | 1200-1800 | 2380 | 45 |
| PRGT40 | 250 | 4000 | 4080 | 2700-3500 | 4080 | 50 |
| PRG1S20 | 1000 | 2000 | 2080 | 1102-1502 | 1490-1990 | 1822-2322 | 1242 | 1904-2404 | 2077 | 464 | 536 | 61 |
| PRG1S30 | 1000 | 3000 | 3080 | 1902-2502 | 3077 | 67 |
| PRG1S40 | 500 | 4000 | 4080 | 1902-3502 | 4077 | 73 |
| PRG1M20 | 1000 | 2000 | 2080 | 1102-1502 | 1728-2428 | 2061-2761 | 1440 | 2143-2843 | 2200 | 65 |
| PRG1M30 | 1000 | 3000 | 3080 | 1902-2502 | 3077 | 71 |
| PRG1M40 | 500 | 4000 | 4080 | 1902-3502 | 4077 | 77 |
| PRG1T20 | 1000 | 2000 | 2080 | 1102-1502 | 1969-2869 | 2301-3201 | 1639 | 2383-3283 | 2830 | 70 |
| PRG1T30 | 1000 | 3000 | 3080 | 1902-2502 | 3077 | 76 |
| PRG1T40 | 500 | 4000 | 4080 | 1902-3502 | 4077 | 82 |
PG aluminum portable gantry is an independent manual gantry that can
be re-positioned within the workshop to suit your operation
and it is easy to disassembled and reassembled as and when
required.It is configurable with manual and electrically-powered
hoists.
| Load capacity(KG) | Model | Eternalwin Dimension Parameter (mm) |
| Hook height(D)mm | Height gain (E)mm | Total height(F)mm | Overall height(H)mm | Width(G)mm |
2000KG
(A=3920mm) | S | 1495-2245 | 5x150 | 2600 | 1931-2681 | 1212 |
| M | 2117-2867 | 5x150 | 3222 | 2553-3303 | 1429 |
| I | 2232-3232 | 5x200 | 3587 | 2668-3668 | 1726 |
| T | 2747-3947 | 6x200 | 4301 | 3183-4383 | 1993 |
| H | 3195-4395 | 6x200 | 4847 | 3730-4930 | 2234 |
| L | 3585-4785 | 6x200 | 5347 | 4230-5430 | 2557 |
| K | 3686-5286 | 8x200 | 5848 | 4330-5930 | 2733 |
| B | 3869-5669 | 9x200 | 6149 | 4431-6231 | 2733 |
3000KG
(A=3920mm) | S | 1545-2295 | 5x150 | 2698 | 2029-2779 | 1212 |
| M | 2167-2917 | 5x150 | 3320 | 2651-3401 | 1429 |
| I | 2282-3282 | 5x200 | 3685 | 2766-3766 | 1726 |
| T | 2797-3997 | 6x200 | 4399 | 3281-4481 | 1993 |
| H | 3245-4445 | 6x200 | 4847 | 3730-4930 | 2234 |
| L | 3745-4945 | 6x200 | 5347 | 4230-5430 | 2557 |
| K | 3846-5446 | 8x200 | 5848 | 4330-5930 | 2733 |
| B | 4029-5829 | 9x200 | 6231 | 4513-6313 | 2733 |
5000KG
(A=3920mm) | I | 2143-3143 | 5x200 | 3592 | 2717-3717 | 1736 |
| T | 2838-4038 | 6x200 | 4487 | 3412-4612 | 2059 |
| H | 3289-4489 | 6x200 | 4938 | 3862-5062 | 2234 |
| L | 3789-4989 | 6x200 | 5438 | 4362-5562 | 2557 |
Key Features:
1)Lightweight and user friendly
2)Corrosion resistant
3)Working spans width is adjustable
4)Mounted on castor wheels in polyurethane
5)2 locking castor's as standard
6)manual trolley optional
Application
1.Manufacturing: Used for lifting and moving heavy machinery and components.
2.Construction: Ideal for on-site lifting tasks, such as positioning beams or
large panels.
3.Warehousing: Useful for loading and unloading materials, and for organizing
heavy inventory.
4.Maintenance: Employed in workshops and garages for lifting engines, gearboxes,
and other heavy parts.
Packing and delivery
FAQ
Q 1: WHAT DO I NEED TO OFFER WHEN PURCHASING CRANES FROM YOU?
There are some necessary parameters about the cranes so you can
tell us the lifting height,loading weight,
span and other details you have. We can offer you a best solution.
Q 2:WHAT PAYMENT METHODS DO YOU HAVE?
You can choose the best way to pay and we have many kinds payment
method ,such as western union,
moneygram, paypal, L/C, T/T. etc.
Q 3: WHAT AFTER-SALE SERVICE CAN YOU OFFER?
We are a professional machinery company so we will offer 24/7
service and whenever you have any doubts
just contact us. We are happy to help you.
Q 4: WHAT TRADE TERMS DO YOU USE?
We often use EXW, FOB, CFR, CPT, CIF, DAP, DDP, DDU price and we
can change according to your requirements.
Q 5: HOW TO SHIP?
The most often shipment method is by sea,which is cheaper than by
air. It depends on clients' decision.
We will try our best to help you.
